Find 8mm Proximity Sensor, 30vdc Non-flush Cheap Proximity Inductive Sensor, Cheap Proximity Inductive Sensor on Industry Directory, Reliable Manufacturer/Supplier/Factory from China.
| Min. Order: | 1 Piece/Pieces |
|---|
Specifications Part number | DC 2 wires NO | LE20SF05DLO | LE20SN08DLO |
| DC 2 wires NC | LE20SF05DLC | LE20SN08DPO |
| Mounting | Flush Non-flush |
| Nominal distance Sn | 5mm 8mm |
| Guaranteed distance Sa | 0......4mm 0.......6.4mm |
| Dimensions | 17*17*38mm |
| Output | NO/NC(Depending on the model) |
| Supply voltage | 10…30 VDC |
| Standard target | Fe 20*20*1t Fe 24*24*1t |
| Switch-point drifts [%/Sr] | ≤±10% |
| Hysteresis range [%/Sr] | 1…20% |
| Repeat accuracy [R] | ≤3% |
| Load current | ≤100mA |
| Residual voltage | ≤8V |
| Current consumption | ≤1mA |
| Circuit protection | Short-circuit,overload and reverse polarity |
| Output indicator | Yellow LED |
| Ambient temperature | -25℃…70℃ |
| Ambient humidity | 35-95%RH |
| Switching frequency [F] | 500HZ 300Hz |
| Voltage withstand | 100V/AC 50/60Hz 60s |
| Insulation resistance | ≥50MΩ(500VDC) |
| Vibration resistance | 10…50Hz (1.5mm) |
| Degree of protection | IP67 |
| Housing material | PBT |
| Connection | 2m PVC cable |
Wiring diagram
Packaging & Shipping PackingPackaging is designed according to specific products for better protection.
Company Information About LanbaoShanghai Lanbao sensing technology Co.,Ltd, member of China Instruments Manufacturers AssociationGoverning Units,established in 1998 in Shanghai, a leading domestic industrial automation product supplier,specializing in the research,development, production, sale and service of industrial sensors, sensor measurement and control systems. Our products cover over 30 series, 5000 specifications, including inductive sensor, Photoelectric Sensor,Capacitive sensor,Light Curtain,laser distance measuring sensors. Our products are widely used in warehouse logistics, parking,elevator,packaging,semi conductor, drone, textile, construction machinery, rail transportation,chemical, robot industry.
Our advantage1 day shipping guarantee for stock item20+ years OEM & ODM history with global top sensor brands20+ years sensor manufacturing experience90+ global R&D patents and copyrights500+ employees(100+in R&D)5000+ specification products33000 sqm factory3,000,000 pcs products per yea Factory show Factory showWe are the first Chinese sensor manufacturer who designs our own smart production workshop:totally 40 products lines including complete production lines which worked with Mitsubishi (Japan). 200 staffsin production line and 3 million products per year.
Why choose us Our certificatesOur standard products already obtained ISO9001, ISO14001, OHSAS18001, CE, UL ,CCC,ROHS certificates.
International ExhibitionsWe attend about 10 international exhibitions every year , for example, IAS(Shanghai), IMTS (US), SPS(Germany),SPS (Guangzhou) and other industrial shows (textile, robot, elevator, logistic etc.) .As a professional sensor manufacturer with core competitiveness and complete value chain, our products sell well in more than 100 countries in the world, allowing more customers to appreciate the charm of “passing the world, sensing the future”.
Our partnersSpecializing in precision,Lanbao always adheres to the business philosophy of”Quality First,Reasonable Price, PromptDelivery, and Attentive Service", maximize the needs and continuously create long-term value and potential growth forcustomers.With comprehensive and efficient services Lanbao's footprint has now spread to more than 100 countries andregions around the world such as US, Canada, Germany Thailand etc.
Our customersSpecializing in precision, Lanbao always adheres to the business philosophy of “Quality First, Reasonable Price, PromptDelivery, and Attentive Service”, maximize the needs and continuously create long-term value and potential growth forcustomers. With comprehensive and efficient services, Lanbao’s footprint has now spread to more than 100 countries and regions around the world ……
Our team
FAQ FAQQ : What is the MOQ?A : 1pcs for our own available designsQ : Can I customize a special sensor?A : SureQ : Can I get a lower price if I order large quantities?A : Yes, Cheaper prices with bigger size ordersQ : Can I get a sample?A : Of course, but you need to pay the minimum sample feeQ : When will you ship my order?A : 1 day shipping guarantee for stock item and 3-4 weeks for non-stock items.Q : How about the quality guarantee period ?A : Our warranty period is one year since from shipping date.Q : Can I add or delete items from my order if I change mind?A : Yes, but you need to tell us asap, if your order has been done in our production line, we cannot change it.Q : How can you guarantee the production quality?A : The quality of our products has passed UL&CE&ISO140001&IS09001certification. We have 20+ years professional sensor manufacturing history and 18+ years ODM labeling experience with global top sensor brands. Contact us
Contact us if you need more details on 8mm Proximity Sensor. We are ready to answer your questions on packaging, logistics, certification or any other aspects about 30vdc Non-flush Cheap Proximity Inductive Sensor、Cheap Proximity Inductive Sensor. If these products fail to match your need, please contact us and we would like to provide relevant information. Product Categories : Inductive Sensor > Standard function-Rectangular
